Introduction
This 40W high power DC-DC Buck converter offers a 6~14V input voltage range and up to 5V/8A output. Featuring a small body, high conversion ratio, strong heat dissipation, and large current output, the module is compatible with all 5V main-boards, and can work as an SMD element to be directly soldered onto PCB. With steady output, this buck converter is able to work for a long time without voltage shift, which can be suitable for projects of high requirements like smart homes, small robot car power sources, etc.
Features
- Small in size
- 40W high power output
- Over 93% conversion ratio
- Can be used as SMD component
- Specification
- Input Voltage Range: 6V-14V
- Output Voltage: 5V
- Output Current: 0-8A
- Voltage Accuracy: ±1%
- Full-load Output Ripple: ＜30mV
- Conversion Ratio: >93% (12V input, full-load output)
- Static Current: <200uA
- Operating Temperature: 0°C~70°C
Shipping List
- DC-DC Buck Converter 6~14V to 5V/8A x1
| Specification | |
| Accuracy | ±1% >93% (12V input, full-load output) convertion ratio |
| Connector | Fermion |
| Output | Analog |
| Resolution | ±1cm |
| Power | 6V-14V |
| Range Output | 5V |
