SATA Power Cable for LattePanda Sigma (PH2.0 4 Pin to SATA 15 Pin, 40cm)
SATA Power Cable for LattePanda Sigma (PH2.0 4 Pin to SATA 15 Pin, 40cm)
Introduction
This is a power supply cable specifically designed for connecting SATA devices to the LattePanda Sigma Single Board Computer.
It features a SATA-15P female connector and a PH2.0-4P terminal, with a cable length of 40cm.
This cable can be used to supply power to SATA interface hard drives or other devices connected to the LattePanda Sigma single-board-computer.
Applications
- LattePanda Sigma Board Power Supply
Specification
- Interface: PH2.0-4P, SATA-15P female connector
- Length: 40cm
- Cable Colors: PH2.0 end - Yellow (12V), Black (GND), Black (GND), Red (5V); SATA end - Yellow, Black, Red, Black
- Wire Gauge: 20AWG
- Insulation Material: PVC insulation
- Conductor Material: Pure copper
- Cable Outer Diameter: OD1.8mm
Shipping List
- SATA to PH2.0 Connection Line for LattePanda Sigma (40cm) x1
| Specification | |
| Cable Lenght | 40cm |
| Connector | Gravity |
| Output | PH2.0-4P, SATA-15P female connector |
| Range Output | 20AWG |
